Specifications


Native Resolution

1920 x 1080

Maximum Resolution

1920 x 1200

Standard Mode Brightness

2200 lm

Native Aspect Ratio

16:9

Compatible Aspect Ratio

4:3

Contrast Ratio

20,000:1

Throw Ratio

0.69 to 0.76   (2540 mm@1500 mm)

Digital Zoom

2x

Vertical Keystone Correction

-30°/+30°

Horizontal Keystone Correction

-30°/+30°

Maximum Vertical Sync

120 Hz

Maximum Horizontal Sync

100 kHz

Minimum Vertical Sync

24 Hz

Minimum Horizontal Sync

15 kHz

Colour Support

1.07 Billion   Colors (30-bit)

Projection Lens

Lens Type

Manual Focus

Manual Zoom

Minimum Lens Aperture

F/2.6

Maximum Lens Aperture

F/2.78

Minimum Focal Length

10.20 mm

Maximum Focal Length

11.22 mm

Minimum Diagonal Image Size

1371.60 mm

Maximum Diagonal Image Size

7.62 m   (300")

Minimum Projection Distance

900 mm

Maximum Projection Distance

4.60 m

Optical Zoom

1.1x

Lamp

Lamp Type

UHP

Number of Lamps

1

Lamp Power

240 W

Normal Mode Lamp Life

3000 Hour

Economy Mode Lamp Life

4000 Hour

ExtremeEco Mode Lamp Life

6000 Hour

Interfaces/Ports

HDMI

Yes

Number of USB Ports

1

USB

Yes

USB Connector Type

Mini-B

Number of Composite Video Ports

1

Composite Video

Yes

Number of Component Video Ports

1

Component Video

Yes

Number of S-Video Ports

1

S-Video

Yes

Number of VGA Inputs

1

VGA In

Yes

Number of VGA Outputs

1

VGA Out

Yes

Number Of Audio Inputs

1

Number Of Audio Outputs

1

Audio Line In

Yes

Audio Line Out

Yes

Total Number of HDMI Ports

3

Technical   Information

Projection System

DLP

Projection Method

·        Ceiling

·        Front

·        Rear

·        Rear Ceiling

Video Compatibility

·        EDTV

·        HDTV

·        NTSC

·        PAL

·        SDTV

·        SECAM

Computer Compatibility

·        Mac PC

·        Windows PC

Audio

Number of Speakers

2

Speaker Output Power

10 W

Speaker Output Mode

Stereo

Power Description

Power Supply

100 V AC~240 V AC

Input Voltage

·        120   V AC

·        230   V AC

Operating Power Consumption

424 W

Operating Power Consumption (Eco Mode)

360 W

Physical   Characteristics

Fan Noise

30 dB Approximate Economy Mode

33 dB Approximate Standard Mode

Temperature

0°C to 40°C

Humidity

80% Maximum Relative Humidity

Weight (Approximate)

3.40 kg

Form Factor

Ceiling Mountable

Miscellaneous

Package Contents

·        Z650 DLP Projector

·        Battery for Remote Control

·        Security Card

·        User's Guide (CD-ROM)

·        Quick Start Guide

·        Remote Control

·        VGA Cable

·        AC Power Cord

·        Carrying Case

·        Optional Accessories
