CHIPSET

AMD B450

MEMORY

AMD Ryzen™ 2nd Generation/   Ryzen™ with Radeon™ Vega Graphics/ Ryzen™ 1st Generation Processors
  4 x DIMM, Max. 64GB, DDR4 3200(O.C.)/3000(O.C.)/2800(O.C.)/2666/2400/2133 MHz   Un-buffered Memory
  Dual Channel Memory Architecture
  ECC Memory (ECC mode) support varies by CPU.
  * Refer to www.asus.com for   the Memory QVL (Qualified Vendors Lists).

GRAPHIC

Integrated in the AMD Ryzen™   with Radeon™ Vega Graphics Processors
  Multi-VGA output support : HDMI/DVI-D/D-Sub ports
  - Supports HDMI 2.0b with maximum resolution of 4096 x 2160 @ 60 Hz
  - Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz
  - Supports D-sub with max. resolution 1920 x 1200 @ 60 Hz

EXPANSION   SLOTS

AMD Ryzen™ 2nd Generation/   Ryzen™ 1st Generation Processors
  1 x PCIe 3.0/2.0 x16 (x16 mode)
  AMD   Ryzen™ with Radeon™ Vega Graphics Processor
  1 x PCIe 3.0/2.0 x16 (x8 mode) *¹
  AMD   B450 chipset
  2 x PCIe 2.0 x1

STORAGE

AMD B450 chipset :
  4 x SATA 6Gb/s port(s),
  Support Raid 0, 1, 10
  AMD   Ryzen™ 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics/ Ryzen™ 1st   Generation Processors :
  2 x SATA 6Gb/s port(s),
  Support Raid 0, 1, 10
  AMD   Ryzen™ 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics/ Ryzen™ 1st   Generation Processors :
  1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices   support (SATA & PCIE 3.0 x 4 mode)*²

LAN

Realtek® RTL8111H, 1 x Gigabit   LAN Controller(s)
  ASUS LAN Guard

AUDIO

Realtek® ALC887 8-Channel High   Definition Audio CODEC
  Audio   Feature :
  - LED-illuminated design - Brighten up your build with the gorgeous   illuminated audio trace path.
  - Audio Shielding: Ensures precision analog/digital separation and greatly   reduced multi-lateral interference
  - Dedicated audio PCB layers: Separate layers for left and right channels to   guard the quality of the sensitive audio signals
  - Premium Japanese audio capacitors: Provide warm, natural and immersive   sound with exceptional clarity and fidelity
  * Choose the chassis with HD audio module in front panel to support 8-channel   audio output.

USB PORTS

AMD Ryzen™ 2nd Generation/   Ryzen™ with Radeon™ Vega Graphics/ Ryzen™ 1st Generation :
  4 x USB 3.1 Gen 1 port(s) (4 at back panel, blue)
  AMD   B450 chipset :
  2 x USB 3.1 Gen 2 port(s) (2 at back panel, )
  AMD B450   chipset :
  2 x USB 3.1 Gen 1 port(s) (2 at mid-board)
  AMD   B450 chipset :
  4 x USB 2.0/1.1 port(s) (4 at mid-board)

SPECIAL FEATURES

ASUS 5X Protection III :
  - ASUS SafeSlot Core: Fortified PCIe Slot prevents damage
  - ASUS LANGuard: Protects against LAN surges, lightning strikes and   static-electricity discharges!
  - ASUS Overvoltage Protection: World-class circuit-protecting power design
  - ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater   durability!
  - ASUS DIGI+ VRM: 6 Phase digital power design
  ASUS   Exclusive Features :
  - AI Suite 3
  - Ai Charger
  ASUS   Quiet Thermal Solution :
  - Stylish Fanless Design Heat-sink solution
  - ASUS Fan Xpert 2+
  ASUS   EZ DIY :
  - ASUS CrashFree BIOS 3
  - ASUS EZ Flash 3
  - ASUS UEFI BIOS EZ Mode
  - Multi-language BIOS
  ASUS Q-Design :
  - ASUS Q-Slot
  - ASUS Q-DIMM

BACK   I/O PORTS

1 x PS/2 keyboard (purple)
  1 x PS/2 mouse (green)
  1 x DVI-D
  1 x D-Sub
  1 x HDMI
  1 x LAN (RJ45) port(s)
  2 x USB 3.1 Gen 2
  4 x USB 3.1 Gen 1 ,
  3 x Audio jack(s)

INTERNAL   I/O PORTS

1 x Aura RGB Strip Header
  1 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.1   Gen 1 port(s) (19-pin)
  2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
  1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices   support (SATA & PCIE 3.0 x 4 mode)
  1 x TPM header
  1 x COM port(s) connector(s)
  6 x SATA 6Gb/s connector(s)
  1 x CPU Fan connector(s) (1 x 4 -pin)
  2 x Chassis Fan connector(s) (2 x 4 -pin)
  1 x S/PDIF out header(s)
  1 x 24-pin EATX Power connector(s)
  1 x 8-pin ATX 12V Power connector(s)
  1 x Front panel audio connector(s) (AAFP)
  1 x System panel(s)
  1 x Clear CMOS jumper(s)
  1 x Speaker connector

ACCESSORIES

User's manual
  I/O Shield
  2 x SATA 6Gb/s cable(s)
  1 x M.2 Screw Package
  1 x Supporting DVD

BIOS

128 Mb Flash ROM, UEFI AMI   BIOS, PnP, SM BIOS 3.1, ACPI 6.1, Multi-language BIOS, ASUS EZ Flash 3, ASUS   CrashFree BIOS 3, F3 My Favorite, Last Modified log, F12 PrintScreen, ASUS   DRAM SPD (Serial Presence Detect) memory information, F6 Qfan Control

OPERATING   SYSTEM

Windows® 10 64-bit

FORM   FACTOR

mATX Form Factor
  9.6 inch x 9.5 inch ( 24.4 cm x 24 cm )

NOTE

1*Support NVMe PCIe RAID.
  2*The M.2 Socket shares bandwidth with the SATA_5/6 ports, and therefore the   SATA_5/6 ports cannot be used when an M.2 device is installed.
