Aten 16 Port PS/2-USB 2.0 VGA KVMP Rack Switch (CS1716A-AT-U)

Aten 16 Port PS/2-USB 2.0 VGA KVMP Rack Switch (CS1716A-AT-U)
  • 50138_thumb_P_1552522798042
  • 50138_thumb_P_1552522815463
  • 50138_thumb_P_1552522815657
$588.5
or 4x fortnightly payments of $330 with ZipPay
Learn more

Pick Up Time :

Delivery:

- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

WishAdd to Wishlist

Buy Now, Pay Later:
Buy now with PayPal
   Your Store   Question Mark

Your store is set to:

Check live stock level
    DELIVERY
    • Post Out Of Stock
    QLD Pickup
    • Southport Out Of Stock
    • Hillcrest Icon 3 Out Of Stock
    • Brendale Out Of Stock
    NSW Pickup
    • Villawood Robot Super StoreIcon 3 Out Of Stock
    • West Ryde Out Of Stock
    • Ultimo Out Of Stock
    • Auburn Out Of Stock
    • Annandale Out Of Stock
    VIC Pickup
    • Mulgrave Robot Super StoreIcon 3 Out Of Stock
    • Mitcham Out Of Stock
    • Essendon Out Of Stock
    • Dandenong South Icon 3 Out Of Stock
    ACT Pickup
    • Fyshwick Out Of Stock
    SA Pickup
    • Croydon Robot Super StoreIcon 3 Out Of Stock
    • Holden Hill Out Of Stock
    • Adelaide CBD Icon 3 Out Of Stock
    WA Pickup
    • Belmont Robot Super StoreIcon 3 Out Of Stock
    • Balcatta Out Of Stock
    TASMANIA Pickup
    • Glenorchy Out Of Stock

Bell  Stock Levels May Vary

Make sure to have the correct store selected. Stock levels are different at every store!
We don't do walk-ins, please make sure to order online for Pickup.

Specifications

  • Product Name:
    Aten 16 Port PS/2-USB 2.0 VGA KVMP Rack Switch (CS1716A-AT-U)
  • Model Number:
    CS1716A-AT-U
  • Brand:
    Aten Aten
  • Manufacturer Warranty:
    2 Year

Description

Aten 16 Port PS/2-USB 2.0 VGA KVMP Rack Switch (CS1716A-AT-U)


  • Superior video quality - up to 2048 x 1536; DDC2B

  • One USB-PS/2 console controls up to 16 computers; Daisy-chain up to 31 additional units - control up to 512 computers from a single console

  • Broadcast Mode - operation simultaneously performed on all selected computers... etc

  • Video DynaSync™ - stores the console monitor EDID to optimize display resolution




Specifications


Computer Connections
Direct16
Maximum512 (via Daisy-chain)
Port SelectionOSD, Hotkey, Pushbutton
Connectors
Console Ports1 x SPHD-18 Male (Yellow)
KVM Ports16 x SPHD-15/17 Female (Yellow)
Daisy Chain Ports1 x DB-25 Female (Black)
1 x DB-25 Male (Black)
Firmware Upgrade1 x RJ-11 Female (Black)
USB Port1 x USB Type A Female
Power1 x DC Jack Female (Black)
LEDs
Online16 (Orange)
Selected16 (Green)
Station ID1 x 2-digit, 7-segment (Orange)
Power1 (Dark Green)
Switches
Port Selection16 x Pushbutton
Firmware Upgrade Recovery1 x Slide
Emulation
Keyboard / MousePS/2, USB
Video2048 x 1536; DDC2B
Scan Interval1 – 255 Seconds (Default: 5 secs)
Power ConsumptionDC5.3V:5.31W:40BTU
Environmental
Operating Temperature0-50˚C
Storage Temperature-20-60˚C
Humidity0-80% RH, Non-condensing
Physical Properties
HousingMetal
Weight2.85 kg ( 6.28 lb )
Dimensions (L x W x H)43.72 x 15.99 x 4.40 cm
(17.21 x 6.3 x 1.73 in.)
NoteFor some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.


Package Contents

  • 1x KVM Switch with Standard Rack Mounting Kit

  • 1x Custom KVM Cable (VGA, USB; 1.8m/6ft)

  • 1x Custom KVM Cable (VGA, PS/2; 1.8m/6ft)

  • 1x Custom Console Cable (VGA, USB, PS/2; 27cm/0.88ft)

  • 1x Firmware Upgrade Cable

  • 1x Foot Pad Set(4 PCS)

  • 1x Power Adapter

  • 1x User Instructions
