SPECIFICATIONS | Weight 144 g Interface/Power USB 2.0, USB Bus Powered DAC Dynamic Range: 130dB (A-weighted), THD+N: ~0.0002%, Sampling Rate (DSP Playback): PCM 16/24/32-bit / 44.1, 48.0, 88.2, 96.0kHz, Sampling Rate (Direct Mode Playback): PCM 16/24/32-bit / 44.1, 48.0, 88.2, 96.0, 176.4, 192.0, 352.8, 384.0 kHz, DoP 24-bit / 176.4 , 352.4 kHz ADC Dynamic Range: 114dB (A-weighted), THD+N: 0.0006%, Sampling Rate (Mic-in): 16/24/32-bit / 44.1, 48.0, 88.2, 96.0, 176.4, 192.0 kHz, Sampling Rate (Line-in, Optical-In): 16/24/32-bit / 44.1, 48.0, 88.2, 96.0, 176.4, 192.0 kHz, Output Impedance: 1 Ω, Supported Headphone Impedance: 16 - 600 Ω, High Gain: 150 - 600 Ω (+14dB), Low Gain: 16 - 149 Ω (+0dB) Audio Technology SB-Axx1™ Connectivity Options (Main) 1 x ⅛″ Line In/mini TOSLINK In Combo Jack, 1 x ⅛″ Line Out/mini TOSLINK Out Combo Jack, 1 x ⅛″ Headphone/Headset Jack, 1 x ⅛″ Ext. Mic In Jack, 1 x microUSB port for PC/Mac Audio Technologies Scout Mode Supported Operating Systems Windows® 7, Windows® 8, Windows Vista®, Windows® 8.1, Windows® 10, Mac OS X v10.8 and above Included Accessories microUSB cable, Mini TOSLINK Cable Dimensions 111 x 70 x 24 mm ASIO Playback & Recording Recommended Usage Gaming |
SYSTEM REQUIREMENTS | Windows® OS · Intel® Core™i3 or AMD® equivalent processor · Intel, AMD or 100% compatible motherboard · Microsoft® Windows 10 32/64 bit, Windows 8.1/8.0 32/64 bit, Windows 7 32/64 bit · 1GB RAM · >600 MB of free hard disk space · USB 2.0 / USB 3.0 port Mac® OS · Mac OS X® 10.9 or higher · 1GB RAM · USB 2.0 / USB 3.0 port PS4 · Firmware Version 5.0 or later · Available USB port · Available Optical Out port (for Dolby Digital decoding) Xbox One · Xbox OS Version 10.0 or later · Available Optical Out port (for Dolby Digital decoding) · External USB Power (not included) · Voice communications not supported Nintendo Switch · Switch OS 5.0 or later · Available 3.5mm headphone port · Available USB port (in docking mode) · External USB Power (not included) · Voice communications not supported |
