CHIPSET

Intel® B365 Express Chipset

MEMORY

2 x DDR4 DIMM sockets supporting up to 32 GB   of system memory

Dual channel memory architecture

Support for DDR4 2666/2400/2133 MHz memory   modules

Support for ECC Un-buffered DIMM 1Rx8/2Rx8   memory modules (operate in non-ECC mode)

Support for non-ECC Un-buffered DIMM   1Rx8/2Rx8/1Rx16 memory modules

Support for Extreme Memory Profile (XMP)   memory modules

* To support 2666 MHz or XMP memory, you must   install a 9th or 8th Generation Intel® Core™ i9/i7/i5 processor.

(Please refer "Memory Support List"   for more information.)

ONBOARD GRAPHICS

Integrated Graphics Processor-Intel® HD   Graphics support:

1 x D-Sub port, supporting a maximum   resolution of 1920x1200@60 Hz

1 x HDMI port, supporting a maximum   resolution of 4096x2160@30 Hz

* Support for HDMI 1.4 version and HDCP 2.2.

Maximum shared memory of 1 GB

Actual support may vary by CPU

AUDIO

Realtek® ALC887 codec

High Definition Audio

2/4/5.1/7.1-channel

* To configure 7.1-channel audio, you have to   use an HD front panel audio module and enable the multi-channel audio feature   through the audio driver.

LAN

Realtek® GbE LAN chip (10/100/1000 Mbit)

EXPANSION SLOTS

1 x PCI Express x16 slot, running at x16

1 x PCI Express x1 slot

(All of the PCI Express slots conform to PCI   Express 3.0 standard.)

STORAGE INTERFACE

Chipset:

1 x M.2 connector (Socket 3, M key, type   2242/2260/2280 SATA and PCIe x4/x2 SSD support)

4 x SATA 6Gb/s connectors

Support for RAID 0, RAID 1, RAID 5, and RAID   10

Intel® Optane™ Memory

USB

Chipset:

6 x USB 3.1 Gen 1 ports (4 ports on the back   panel, 2 ports available through the internal USB header)

6 x USB 2.0/1.1 ports (2 ports on the back   panel, 4 ports available through the internal USB headers)

INTERNAL I/O CONNECTORS

1 x 24-pin ATX main power connector

1 x 8-pin ATX 12V power connector

1 x CPU fan header

1 x system fan header

1 x M.2 Socket 3 connector

4 x SATA 6Gb/s connectors

1 x front panel header

1 x front panel audio header

1 x USB 3.1 Gen 1 header

2 x USB 2.0/1.1 headers

1 x Trusted Platform Module (TPM) header (2x6   pin, for the GC-TPM2.0_S module only)

1 x serial port header

1 x Clear CMOS jumper

BACK PANEL CONNECTORS

1 x PS/2 mouse port

1 x PS/2 keyboard port

1 x D-Sub port

1 x HDMI port

4 x USB 3.1 Gen 1 ports

2 x USB 2.0/1.1 ports

1 x RJ-45 port

3 x audio jacks

I/O CONTROLLER

iTE® I/O Controller Chip

H/W MONITORING

Voltage detection

Temperature detection

Fan speed detection

Overheating warning

Fan fail warning

Fan speed control

* Whether the fan speed control function is   supported will depend on the cooler you install.

BIOS

2 x 128 Mbit flash

Use of licensed AMI UEFI BIOS

PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI   5.0

UNIQUE FEATURES

Support for APP Center

* Available applications in APP Center may   vary by motherboard model. Supported functions of each application may also   vary depending on motherboard specifications.

@BIOS

AutoGreen

Cloud Station

EasyTune

Easy RAID

Fast Boot

Game Boost

ON/OFF Charge

Platform Power Management

RGB Fusion

Smart Backup

Smart Keyboard

Smart Survey

System Information Viewer

USB Blocker

Support for Q-Flash

Support for Xpress Install

BUNDLED SOFTWARE

Norton® Internet Security (OEM version)

Realtek 8118 Gaming LAN bandwidth Control   Utility

OS

Support for Windows 10 64-bit

FORM FACTOR

Micro ATX Form Factor; 565px x 462.5px

REMARK

Due to different Linux support condition   provided by chipset vendors, please download Linux driver from chipset   vendors' website or 3rd party website.

Most hardware/software vendors may no longer   offer drivers to support Win9X/ME/2000/XP. If drivers are available from the   vendors, we will update them on the GIGABYTE website.
