Operating System |
|
Preinstalled | · Windows 10 Pro for Workstations 64 · Windows 10 Pro 64 (recommended by HP) · Windows 10 Pro 64 (National Academic License) · Windows 10 Home 64 · HP Linux Ready |
Supported | Red Hat Enterprise Linux (RHEL) Workstation (12-month paper license available, not preinstalled) |
Processors |
|
Intel Xeon E-2176G processor | Up to 4.7 GHz with Intel Turbo Boost Technology (3.7 GHz base frequency) 12 MB cache and 6 cores Intel UHD Graphics P630 DDR4 memory up to 2666 MT/s data rate 80 W TDP Intel vPro Technology |
Intel Xeon E-2174G processor | Up to 4.7 GHz with Intel Turbo Boost Technology (3.8 GHz base frequency) 8 MB cache and 4 cores Intel UHD Graphics P630 DDR4 memory up to 2666 MT/s data rate 71 W TDP Intel vPro Technology |
Intel Xeon E-2136 processor | Up to 4.5 GHz with Intel Turbo Boost Technology (3.3 GHz base frequency) 12 MB cache and 6 cores DDR4 memory up to 2666 MT/s data rate 80 W TDP Intel vPro Technology |
Intel Xeon E-2124G processor | Up to 4.3 GHz with Intel Turbo Boost Technology (3.4 GHz base frequency) 8 MB cache and 4 cores Intel UHD Graphics P630 DDR4 memory up to 2666 MT/s data rate 71 W TDP Intel vPro Technology |
Intel Xeon E-2104G processor | 3.2 GHz Base frequency 8 MB cache and 4 cores Intel UHD Graphics P630 DDR4 memory up to 2666 MT/s data rate 65 W TDP Intel vPro Technology |
Intel Core i7-8700 processor | Up to 4.6 GHz with Intel Turbo Boost Technology (3.2 GHz base frequency) 12 MB cache and 6 cores Intel UHD Graphics 630 DDR4 memory up to 2666 MT/s data rate 65 W TDP Intel vPro Technology |
Intel Core i5-8600 processor | Up to 4.2 GHz with Intel Turbo Boost Technology (3.1 GHz base frequency) 9 MB cache and 6 cores Intel UHD Graphics 630 DDR4 memory up to 2666 MT/s data rate 65 W TDP Intel vPro Technology |
Intel Core i5-8500 processor | Up to 4.0 GHz with Intel Turbo Boost Technology (3.0 GHz base frequency) 9 MB cache and 6 cores Intel UHD Graphics 630 DDR4 memory up to 2666 MT/s data rate 65 W TDP Intel vPro Technology |
Intel Core i3-8100 processor | 3.6 GHz Base frequency 6 MB cache and 4 cores Intel UHD Graphics 630 DDR4 memory up to 2400 MT/s data rate 65 W TDP |
Intel Pentium Gold G5400 processor | 3.7 GHz base frequency 4 MB cache and 2 cores Intel UHD Graphics 610 DDR4 memory up to 2400 MT/s data rate 54 W |
Intel Core i5/Core i7 and Xeon with vPro technology capable | Intel Virtualization Technology (Intel VT) Intel Active Management Technology (iAMT) NOTE: For Windows operating system only. Future virtual appliances applications dependent on third-party software and compatibility to be determined. |
Chipset | Intel PCH C246 |
Graphics |
|
Integrated | Intel UHD Graphics P630 Intel UHD Graphics 630 Intel UHD Graphics 610 NOTE: Single graphic card supported. |
Entry 3D | NVIDIA Quadro P400 2GB Graphics NVIDIA Quadro P620 2GB Graphics NOTE: Two graphic card supported. Radeon Pro WX3100 4GB Graphics (single graphic card supported) |
Mid-range 3D | Radeon Pro WX4100 4GB 1st GFX Graphics NVIDIA Quadro P1000 4GB Graphics NOTE: Single graphic card supported. |
Graphics cable adapters | HP DisplayPort to DVI-D Adapter HP DisplayPort to DVI-D Adapter (2-Pack) HP DisplayPort to HDMI Adapter (4-Pack) HP DisplayPort to Dual Link DVI Adapter HP DisplayPort to VGA Adapter HP DisplayPort to HDMI Adapter HP mini-DisplayPort to DP Adapter HP USB-C to VGA Adapter HP USB-C to HDMI Adapter HP USB-C to DP Adapter |
Memory |
|
Standard | (4) SODIMM slots supporting dual-channel memory 4 GB, 8 GB, and 16 GB SODIMMs |
Supported configurations | 8 GB (1 x 8 GB) DDR4-2666 ECC SODIMM 16 GB (2 x 8 GB) DDR4-2666 ECC SODIMM 32 GB (4 x 8 GB) DDR4-2666 ECC SODIMM 32 GB (2 x 16 GB) DDR4-2666 ECC SODIMM 64 GB (4 x 16 GB) DDR4-2666 ECC SODIMM NOTE: Intel Core i5/i7 processors only support non-ECC memory. 4 GB (1 x 4 GB) DDR4-2666 non-ECC SODIMM 8 GB (2 x 4 GB) DDR4-2666 non-ECC SODIMM 8 GB (1 x 8 GB) DDR4-2666 non-ECC SODIMM 16 GB (2 x 8 GB) DDR4-2666 non-ECC SODIMM 32 GB (4 x 8 GB) DDR4-2666 non-ECC SODIMM 32 GB (2 x 16 GB) DDR4-2666 non-ECC SODIMM 64 GB (4 x 16 GB) DDR4-2666 non-ECC SODIMM NOTE: ECC and non-ECC memory DIMMs cannot be mixed on the same system. |
Maximum | Up to 64 GB |
Monitors/Displays |
|
Supported | HP Z Display Z27n G2 27-inch IPS LED Backlit Monitor HP Z Display Z24n G2 24-inch IPS LED Backlit Monitor HP Z Display Z24nf G2 23.8-inch IPS Backlit Monitor HP Z Display Z23n G2 23-inch IPS LED Backlit Monitor HP Z Display Z22n G2 21.5-inch IPS LED Backlit Monitor |
Storage and Drives |
|
SATA 8.89 cm (3.5 in) Hard Drives | HP 500GB SATA 6Gb/s 7200 Hard Drive HP 1TB SATA 6Gb/s 7200 Hard Drive HP 2TB SATA 6Gb/s 7200 Hard Drive HP 4TB SATA 7200 Hard Drive HP 6TB Enterprise SATA 7200 HDD 500 GB SATA 7200 rpm SED SFF HDD HP 1 TB 7200 RPM SATA 8GB SSHD Drive HP 1TB Enterprise SATA 7200 HDD |
SATA SSD | HP 256GB SATA Solid State Drive HP 512GB SATA Solid State Drive HP 1TB Solid State Drive HP 2TB SATA SSD HP 256GB SATA SED Opal2 Solid State Drive |
PCIe Solid State Drives | HP Z Turbo Drive G2 256 GB TLC SSD HP Z Turbo Drive G2 512 GB TLC SSD HP Z Turbo Drive G2 1 TB TLC SSD |
Removable storage | HP 9.5mm Slim SuperMulti DVD Writer HP 9.5mm Slim DVD-ROM Optical Drive HP 9.5mm Slim BDXL Blu-Ray Writer Drive |
HDD Frame/carriers | HP DP25 Removable 2.5in HDD Frame Carrier HP DP25 Removable 2.5in HDD Spare Carrier |
Media card reader | HP SD Media Card Reader |
Ports/Slots |
|
Ports | Front side (1) Power button (1) Headphone/microphone combo jack (1) USB 3.0 Type-A charging data port (1) USB 3.0 Type-A data port (1) USB 3.1 Gen 2 Type-C charging data port (optional) (1) SD Card Reader (optional) (1) External/internal shared 8.89 cm (3.5 in) bay (1) Slim ODD bay Back I/O ports (1) WLAN/BT antenna (optional) (1) Audio Line-In (1) Audio Line-Out (2) DisplayPort (DP) 1.2 outputs (from Intel UHD graphics; select models) (1) Flexible module port output (optional flexible module required) (2) USB 2.0 ports (4) USB 3.0 ports (1) Serial port (optional) (1) RJ-45 to integrated GBE PS/2 ports (optional) (1) DC Input Internal I/O ports (1) USB 3.0 port (2) USB 2.0 ports NOTE: Available as 2 separate 2 x6 (3.0 x1, 2.0 x1) and 1 x6 (2.0 x1) header: supports one USB 3.0 Media Card Reader. |
Controller card | HP Thunderbolt 3 PCIe 3-port I/O Card NOTE: Utilizes Flex IO port internal connection for video output. |
Rear module options | HP Flex IO module (VGA) HP Flex IO module (HDMI) HP Flex IO module (DP) HP Flex IO module (USB-C) HP Flex IO module (1 GbE LAN) |
Expansion slots | (1) PCI Express Gen3 slot x16 mechanical/ x16 electrical (1) PCI Express Gen3 slot x4 mechanical/ x1 electrical (1) PCI Express Gen3 slot x4 mechanical/ x1 electrical (1) PCI Express Gen3 slot x16 mechanical/ x4 electrical (2) M.2 storage (PCIe Gen3 x4) (1) M.2 Wlan (PCIe Gen3 x1 and Intel CNVi) NOTE: All slots are Low Profile. M.2 storage supports compatible devices at 80 mm. The PCIe Gen 3 x16 slot is meant for HP qualified cards, configured or after market. HP does not provide warranty support for 3rd party cards. |
Bays | (1) External/internal shared 8.89 cm (3.5 in) bay |
Audio/Multimedia |
|
Keyboard | HP USB Business Slim CCID SmartCard Keyboard HP USB Business Slim Keyboard HP PS/2 Business Slim Keyboard HP USB Premium Keyboard HP Premium Wireless Keyboard HP Wireless Business Slim Keyboard & Mouse |
Mouse | HP USB Optical Mouse HP PS/2 Mouse HP USB Hardened Mouse HP USB Premium Mouse HP Premium Wireless Mouse SpaceMouse Pro USB 3D Input Device 3Dconnexion CADMouse |
Other devices | HP Power Cord Kit HP Workstation Mouse Pad (Japan only) HP Serial Port Adapter HP Serial and PS/2 Adapter HP PCIe x1 Parallel Port Card HP (SFF) Tower Stand HP Z2 SFF G4 Bezel with Dust Filter option HP Z2 SFF G4 Dust filter only |
Networking/Communication |
|
Integrated | Intel I219LM PCIe GbE Controller (Intel vPro with Intel AMT 12.0) Intel X710-DA2 2-Port 10GbE SFP+ NIC HP 10GbE SFP+ SR Transceiver Intel X550-T2 2-Port 10GbE NIC Intel 9560 802.11a/b/g/n/ac with Bluetooth 5 M.2 NOTE: If AMT is provisioned, then network teaming with the integrated LAN port is not possible. Intel I350-T2 2-Port 1GbE NIC Intel I350-T2 4-Port 1GbE NIC NOTE: "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/sec. For high speed transmission, connection to a Gigabit Ethernet server and network infrastructure is required. |
Software/Security |
|
BIOS | HP BIOSphere Gen4 (features vary) HP DriveLock/HP Automatic DriveLock BIOS Update via Network Master Boot Record Security Power On Authentication Secure Erase (methods outlined in the National Institute of Standards and Technology Special Publication 800-88) Absolute Persistence Module1 Pre-boot Authentication |
Communication/connectivity | HP Wireless Wakeup |
HP Value Add software | HP Performance Advisor (preinstalled with Windows 10 only) HP Remote Graphics Software (RGS) HP PC Hardware Diagnostics UEFI (Windows OS only) HP Hotkey Support - CMIT HP Sure Click HP Sure Start Gen4 HP Sure Run (requires Intel 8th generation processors) HP Sure Recover (requires Intel 8th generation processors and wired network connection) |
Manageability | HP System Software Manager (SSM) HP Client Catalog HP BIOS Configuration Utility (BCU) HP Driver Packs (available for download) HP Manageability Integration Kit Gen2 (available for download) |
Client Security software | Microsoft Defender HP Client Security Manager Gen4 (requires Windows and Intel 8th generation processors) HP Security Manager (including Credential Manager, HP Password Manager, HP Spare Key) HP Device Access Manager HP Power On Authentication |
Security | For Windows 10, Trusted Platform Module (TPM) 2.0 (Infineon SLB9670) Common Criteria EAL4+ Certified RAID configurations (optional and requires a second hard drive) Power-on password (via BIOS) Setup password (via BIOS) SATA port disablement (via BIOS) Serial, USB enable/disable (via BIOS) Integrated hood sensor |
Power |
|
Power supply | 310 W Power supply 90% efficiency Wide-ranging Active PFC 250 W Power supply 85% efficiency Wide-ranging Active PFC |
Rated input current | 4 A at 100 to 240 V |
Operating voltage range | 90 to 264 VAC |
Operating line frequency range | 47 to 63 Hz |
Physical specifications |
|
Dimensions (H x W x D) | Desktop orientation 100.3 x 337.8 x 381.0 mm (3.95 x 13.3 x 15.0 in) SFF Tower orientation (excluding stand) 337.8 x 100.3 x 381.0 mm (13.3 x 3.95 x 15.0 in) Packaging 499.11 x 229.11 x 517.91 mm (19.65 x 9.02 x 20.39 in) |
Weight | Typical weight 6.3 kg (13.89 lb) NOTE: Configured with one 8.89 cm (3.5 in) hard drive, one optical drive, two DIMMs, and one NVIDIA Quadro P620 graphics card. Shipping weight 9.35 kg (20.61 lb) |
Environmental |
|
Certifications | ENERGY STAR (energy-saving features available on selected configurations – Windows only) IT ECO declaration US Federal Energy Management Program (FEMP) China Energy Conservation Program (CECP) Low Halogen NOTE: External power supplies, power cords, cables and peripherals are not low halogen. Service parts obtained after purchase might not be low halogen. |
Temperature | Operating 5° to 35°C (41° to 95°F) Non-operating -40° to 60°C (-40° to 140°F) |
Relative humidity | Operating 10% to 85%, non-condensing Non-operating 10% to 90%, non-condensing |
Altitude (unpressurized) | Operating 3,048 m (10,000 ft) Non-operating 12,192 m (15,000 ft) |
