ESSENTIALS |
|
Product Collection | 12th Generation Intel® Core⢠i9 Processors |
Code Name | Products formerly Alder Lake |
Vertical Segment | Desktop |
Processor Number | i9-12900KS |
Lithography | Intel 7 |
CPU SPECIFICATIONS |
|
Total Cores | 16 |
# of Performance-cores | 8 |
# of Efficient-cores | 8 |
Total Threads | 24 |
Max Turbo Frequency | 5.50 GHz |
IntelĀ® Thermal Velocity Boost Frequency | 5.50 GHz |
IntelĀ® Turbo Boost Max Technology 3.0 Frequency* | 5.30 GHz |
Performance-core Max Turbo Frequency | 5.20 GHz |
Efficient-core Max Turbo Frequency | 4.00 GHz |
Performance-core Base Frequency | 3.40 GHz |
Efficient-core Base Frequency | 2.50 GHz |
Cache | 30 MB IntelĀ® Smart Cache |
Total L2 Cache | 14 MB |
Processor Base Power | 150 W |
Maximum Turbo Power | 241 W |
MEMORY SPECIFICATIONS |
|
Max Memory Size (dependent on memory type) | 128 GB |
Memory Types | Up to DDR5 4800 MT/s Up to DDR4 3200 MT/s |
Max # of Memory Channels | 2 |
Max Memory Bandwidth | 76.8 GB/s |
ECC Memory Supported* | Yes |
PROCESSOR GRAPHICS |
|
Processor Graphics* | IntelĀ® UHD Graphics 770 |
Graphics Base Frequency | 300 MHz |
Graphics Max Dynamic Frequency | 1.55 GHz |
Graphics Output | eDP 1.4b, DP 1.4a, HDMI 2.1 |
Execution Units | 32 |
Max Resolution (HDMI)* | 4096 x 2160 @ 60Hz |
Max Resolution (DP)* | 7680 x 4320 @ 60Hz |
Max Resolution (eDP - Integrated Flat Panel)* | 5120 x 3200 @ 120Hz |
DirectX Support | 12 |
OpenGL Support | 4.5 |
Multi-Format Codec Engines | 2 |
IntelĀ® Quick Sync Video | Yes |
IntelĀ® Clear Video HD Technology | Yes |
# of Displays Supported* | 4 |
Device ID | 0x4680 |
OpenCL Support | 2.1 |
EXPANSION OPTIONS |
|
Direct Media Interface (DMI) Revision | 4.0 |
Max # of DMI Lanes | 8 |
Scalability | 1S Only |
PCI Express Revision | 5.0 and 4.0 |
PCI Express Configurations* | Up to 1x16+4, 2x8+4 |
Max # of PCI Express Lanes | 20 |
PACKAGE SPECIFICATIONS |
|
Max CPU Configuration | 1 |
Thermal Solution Specification | PCG 2022E |
Intel® Thermal Velocity Boost Temperature | 50°C |
Package Size | 45.0 mm x 37.5 mm |
ADVANCED TECHNOLOGIES |
|
IntelĀ® Gaussian & Neural Accelerator | 3.0 |
IntelĀ® Thread Director | Yes |
IntelĀ® Deep Learning Boost (IntelĀ® DL Boost) | Yes |
Intel® Optane⢠Memory Supported* | Yes |
IntelĀ® Speed Shift Technology | Yes |
IntelĀ® Adaptive Boost Technology | Yes |
IntelĀ® Thermal Velocity Boost | Yes |
IntelĀ® Turbo Boost Max Technology 3.0* | Yes |
IntelĀ® Turbo Boost Technology* | 2.0 |
IntelĀ® Hyper-Threading Technology* | Yes |
IntelĀ® 64* | Yes |
Instruction Set | 64-bit |
Instruction Set Extensions | IntelĀ® SSE4.1, IntelĀ® SSE4.2, IntelĀ® AVX2 |
Idle States | Yes |
Enhanced Intel SpeedStepĀ® Technology | Yes |
Thermal Monitoring Technologies | Yes |
IntelĀ® Volume Management Device (VMD) | Yes |
SECURITY & RELIABILITY |
|
Intel vProĀ® Platform Eligibility* | Yes |
Intel vProĀ® Enterprise Platform Eligibility* | Yes |
IntelĀ® Threat Detection Technology (TDT) | Yes |
IntelĀ® Active Management Technology (AMT)* | Yes |
IntelĀ® Standard Manageability (ISM)* | Yes |
IntelĀ® One-Click Recovery* | Yes |
IntelĀ® Hardware Shield Eligibility* | Yes |
IntelĀ® AES New Instructions | Yes |
Secure Key | Yes |
IntelĀ® OS Guard | Yes |
Execute Disable Bit* | Yes |
IntelĀ® Boot Guard | Yes |
Mode-based Execute Control (MBEC) | Yes |
IntelĀ® Control-Flow Enforcement Technology | Yes |
IntelĀ® Total Memory Encryption - Multi Key | Yes |
IntelĀ® Total Memory Encryption | Yes |
IntelĀ® Virtualization Technology (VT-x)* | Yes |
IntelĀ® Virtualization Technology for Directed I/O (VT-d)* | Yes |
IntelĀ® VT-x with Extended Page Tables (EPT)* | Yes |
