Panel Size

31.5 inch / 80 cm

Aspect ratio

16:9

LCD panel type

VA LCD

Backlight type

W-LED system

Pixel pitch

0.2724 x 0.2724 mm

Brightness

300  cd/m²

Display colors

16.7 M

Color gamut (typical)

NTSC 106%*, sRGB 120%*

Contrast ratio (typical)

3500:1

SmartContrast

Mega Infinity DCR

Response time (typical)

1 ms (Gray to Gray)*

Viewing angle

178º (H) / 178º (V)

@ C/R > 10

Picture enhancement

SmartImage game

Maximum resolution

HDMI: 2560 x 1440 @ 144 Hz, DP: 2540 x 1440 @ 180 Hz*

Effective viewing area

697.344 (H) x 392.256 (V) - at a 1500R curvature*

Scanning Frequency

HDMI: 30 - 230 kHz (H) / 48 - 144 Hz (V), DP: 30 - 270 kHz (H) / 48 -   180 Hz (V)

sRGB

Yes

Delta E

< 2 (sRGB)

Flicker-free

Yes

Pixel Density

93.24 PPI

LowBlue Mode

Yes

Display Screen Coating

Anti-Glare, 3H, Haze 25%

Low Input Lag

Yes

EasyRead

Yes

HDR

HDR 10 supported

Smart MBR

0.5ms*

CONNECTIVITY

Signal Input

HDMI 2.0 x 2, DisplayPort 1.4 x 1

Sync Input

Separate Sync

Audio (In/Out)

Audio out

HDCP

HDCP 1.4 (HDMI / DisplayPort), HDCP 2.2 (HDMI / DisplayPort)

CONVENIENCE

Plug & Play Compatibility

DDC/CI

Mac OS X

sRGB

Windows 11 / 10

User convenience

Power On/Off

Menu/OK

Input/Up

Game Settings/Down

SmartImage game/Back

OSD Languages

Brazil Portuguese

Czech

Dutch

English

Finnish

French

German

Greek

Hungarian

Italian

Japanese

Korean

Polish

Portuguese

Russian

Spanish

Simplified Chinese

Swedish

Turkish

Traditional Chinese

Ukrainian

Other convenience

Kensington lock

VESA mount (100x100mm)

STAND

Tilt

-5/20  degree

POWER

Power supply

Internal

100-240VAC, 50-60Hz

Off mode

0.3 W (typ.)

On mode

33.8 W (typ.)

Standby mode

0.5 W (typ.)

Power LED indicator

Operation - White

Standby mode- White (blinking)

DIMENSIONS

Packaging in mm (WxHxD)

780 x 520 x 188 mm

Product without stand (mm)

709 x 462 x 96 mm

Product with stand(max height)

709 x 519 x 250 mm

WEIGHT

Product with packaging (kg)

9.03  kg

Product with stand (kg)

6.85  kg

Product without stand (kg)

6.02  kg

OPERATING CONDITIONS

Altitude

Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m)

Temperature range (operation)

0°C to 40  °C

MTBF

50,000 (Excluded backlight) hour(s)

Relative humidity

20%-80  %

Temperature range (storage)

-20°C to 60  °C

SUSTAINABILITY

Environmental and energy

RoHS

Recyclable packaging material

100  %

Specific Substances

Mercury free

PVC / BFR free housing

COMPLIANCE AND STANDARDS

Regulatory Approvals

CB

TUV/ISO9241-307

TUV-BAUART

EAC

EAEU RoHS

PSB

CE Mark

UKCA

EMF

FCC

ICES-003
