Connection to PC: Thunderbolt™ 3 using included 40Gbps cable
Compatible Laptops: Razer Blade Stealth, Razer Blade, and Razer Blade Pro laptops with Thunderbolt™ 3.
Additional laptops require a Thunderbolt™ 3 port with external graphics support. Please check with your laptop manufacture to confirm if your laptop supports external graphics.
Razer Core X max inner dimensions: Length : 12.99”/ 330 mm
Height*: 6.29” / 160 mm
Width : 2.36” / 60 mm
* Height measured from top of PCIe connector to the bottom of the locking pin ramps.
System Requirements: Windows® 10 64bit RS1 or above with Thunderbolt™ 3 port
Macs running macOS High Sierra 10.13.4 or later.
GPU Support (Graphics card not included): GPU Type: Up to 3-Slot wide, full-length, PCI-Express x16 graphics card
GPU Max Power Support: 500W
Windows 10 compatible graphics chipsets: NVIDIA® GeForce® GTX Titan X
NVIDIA® GeForce® GTX Titan V
NVIDIA® GeForce® GTX Titan Xp
NVIDIA® GeForce® GTX 1080 Ti
NVIDIA® GeForce® GTX 1080
NVIDIA® GeForce® GTX 1070 Ti
NVIDIA® GeForce® GTX 1070
NVIDIA® GeForce® GTX 1060
NVIDIA® GeForce® GTX 1050 Ti
NVIDIA® GeForce® GTX 1050
NVIDIA® GeForce® GTX 980 Ti
NVIDIA® GeForce® GTX 980
NVIDIA® GeForce® GTX 970
NVIDIA® GeForce® GTX 960
NVIDIA® GeForce® GTX 950
NVIDIA® GeForce® GTX 750 Ti
NVIDIA® GeForce® GTX 750
NVIDIA® Quadro® P4000
NVIDIA® Quadro® P5000
NVIDIA® Quadro® P6000
NVIDIA® Quadro® GP100
AMD Radeon™ VEGA RX 64
AMD Radeon™ VEGA RX 56
AMD Radeon™ RX 500 Series
AMD Radeon™ RX 400 Series
AMD Radeon™ R9 Fury
AMD Radeon™ R9 Nano
AMD Radeon™ R9 300 Series
AMD Radeon™ R9 290X
AMD Radeon™ R9 290
AMD Radeon™ R9 285
AMD Radeon RX 570
AMD Radeon RX580
AMD Radeon Pro WX 7100
AMD Radeon RX Vega 56
AMD Radeon RX Vega 64
AMD Vega Frontier Edition Air
AMD Radeon Pro WX 9100
Input & Output: Thunderbolt™ 3 (for connection to PC)
Internal Power Supply: 650W
Laptop Power Delivery: Up to 100W via USB-C
Included Cables: Power Cable
Thunderbolt™ 3 cable
Razer Core Approx. Size: 6.61" / 168 mm (Width) x 14.72" / 374 mm (Depth) x 9.06" / 230 mm (Height)
