Simplecom HDMI 2.0 1x2 Splitter with 2 Port HDMI Duplicator (CM412)

$32.0

or 4x fortnightly payments of $330 with ZipPay
Learn more

Pick Up Time : Question Mark

Delivery: Question Mark

- +

Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

Wish Add to Wishlist

Buy Now, Pay Later:

Your Store

Your store is set to:

Check live stock level

Stock Levels May Vary

Make sure to have the correct store selected. Stock levels are different at every store!
We don't do walk-ins, please make sure to order online for Pickup.

Specifications

Product Name:

Simplecom HDMI 2.0 1x2 Splitter with 2 Port HDMI Duplicator (CM412)
Model Number:

CM412
Brand:

Simplecom
Warranty Period:

1 Year

Description

Please note: The product only allows the display to be duplicated not extended it will display the same picture on both outputs

CM412 is a 2 Port HDMI 1x2 splitter, allows to duplicate one HDMI signal source device to two displays. CM412 supports video resolutions up to 4Kx2K@60Hz, as well as HDR10 and HDCP2.2 compliant.

Widely compatible HDMI devices with HDMI 2.0 support, ideal for latest online streaming box and game console with 4K HDMI output. With downscaling feature, you can use different resolution monitors*, it allows you to play game in 4K from HDMI output 1 and capture in 1080p from HDMI output 2 under Mixed mode.

Simultaneously transmit video and audio from one HDMI source to two HDMI displays
Auto detects and configures video resolution according to the capabilities of each connected display*
Downscaling feature, output 4K and 1080p simultaneously
Support HDMI 2.0b, backwards compatible with HDMI 1.4 and HDMI 1.3
Support HDCP 2.2, also compatible with HDCP 1.4
Support resolution up to 4K@60Hz (3840X2160)
Support 3D, HDR10 (High Dynamic Range)
LED indication for power and signal
Plug and play, no software required

SPECIFICATIONS:

HDMI Version	HDMI 2.0b
HDMI Resolution	480i/480p/576i/576p/720p/1080i/1080p/2160p@ 60Hz
Input Ports	1 x HDMI (Female type)
Output Ports	2 x HDMI (Female type)
Video Support	up to 4K@60hz YUV 4:4:4, 4K@60hz with HDR YUV 4:2:0
Audio Format Support	DTS-HD, Dolby True HD, Dolby Digital Plus, LPCM 7.1
HDR Format Support	HDR10
HDCP Version Support	HDCP 2.2
Max Bandwidth	18Gbps
Max Input cable distance	1080p<10m, 4K<5m (28AWG HDMI 19+1 cable)
Max Output cable distance	1080p<10m, 4K<5m (28AWG HDMI 19+1 cable)
Max Power Consumption	5W
Power requirement	USB DC 5V1A
Operating Temperature	(-15 to +55°C)
Dimension (L x W x H)	58x48x12mm
