TP-Link 16 Port 10/100/1000 Gigabit Rack Mountable Switch (TL-SG1016D)

TP-Link 16 Port 10/100/1000 Gigabit Rack Mountable Switch (TL-SG1016D)
  • Switches-TP-Link-16-Port-10-100-1000-Gigabit-Rack-Mountable-Switch-4
  • Switches-TP-Link-16-Port-10-100-1000-Gigabit-Rack-Mountable-Switch-1
  • Switches-TP-Link-16-Port-10-100-1000-Gigabit-Rack-Mountable-Switch-2
$74.0 Question Mark
Was: $99.0  WAS Tips    25% Off!  Save $25.0
or 4x fortnightly payments of $330 with ZipPay
Learn more

Pick Up Time :

Delivery:

- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

WishAdd to Wishlist

Buy Now, Pay Later:
Buy now with PayPal
   Your Store   Question Mark

Your store is set to:

Check live stock level

Bell  Stock Levels May Vary

Make sure to have the correct store selected. Stock levels are different at every store!
We don't do walk-ins, please make sure to order online for Pickup.

Specifications

  • Product Name:
    TP-Link 16 Port 10/100/1000 Gigabit Rack Mountable Switch (TL-SG1016D)
  • Model Number:
    TL-SG1016D
  • Brand:
  • Warranty Period:
    5 Year

Description

TP-Link 16 Port 10/100/1000 Gigabit Rack Mountable Switch
The TL-SG1016D Gigabit Ethernet Switch provides you with a high-performance, low-cost, easy-to-use, seamless and standard upgrade to improve old network to 1000Mbps network. All 16 ports support auto MDI/MDIX, no need to worry about the cable type, simply plug and play. Moreover, with the innovative energy-efficient technology, the TL-SG1016D can save power consumption, making it an eco-friendly solution for your business network.

TP-LINK Green Technology

This new generation TL-SG1016D Gigabit Switch features the latest innovative energy-efficient technologies that can greatly expand your network capacity with much less power. It automatically adjusts power consumption according to the link status to limit the carbon footprint of your network. It also complies with the EU’S RoHS, prohibiting the use of certain hazardous materials. Besides, most packaging material can be recycled.


High Performance

All 16 ports are Gigabit RJ-45 ports which can provide large file transferring and also be compatible with 10Mbps and 100Mbps Ethernet devices. Featuring non-blocking switching architecture, TL-SG1016D forwards and filters packets at full wire-speed for maximum throughput. With 10KB Jumbo frame, the performance of large files transfers is improved significantly. And IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode alleviate the traffic congestion and make The TL-SG1016D work reliably. It’s a perfect choice to update your network to Gigabit while protecting your previous investment properly.


Easy to Use

The auto features of this gigabit switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDIX eliminates the need for crossover cables. Auto-negotiation on each port senses the link speed of a network device (10, 100, or 1000 Mbps) and intelligently adjusts for compatibility and optimal performance.





SPECIFICATIONS:

HARDWARE FEATURES


Standards and Protocols

IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x

Interface

16 10/100/1000Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)

Network Media

10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)

100BASE-TX/1000BASE-T: UTP category 5, 5e or above cable (maximum 100m)

Fan Quantity

Fanless

Dimensions ( W x D x H )

11.6*7.1*1.7 in. (294*180*44 mm)

Power Consumption

Maximum: 13.3W (220V/50Hz)

Power Supply

100-240VAC, 50/60Hz

PERFORMANCE


Switching Capacity

32Gbps

MAC Address Table

8K

Packet Forwarding Rate

23.8Mpps

Jumbo Frame

10KB

Green Technology

Innovative energy-efficient technology saves power up to 15%

Transfer Method

Store-and-Forward

OTHERS


Certification

FCC, CE, RoHS

FCC, CE, RoHS

16-Port Gigabit Desktop/Rackmount Switch

Power Cord

Installation Guide

Rackmount Kits

Rubber Feet

System Requirements

Microsoft® Windows® XP, Vista, Windows 7 or Windows 8, MAC® OS,   NetWare®, UNIX® or Linux.

Environment

Operating Temperature: 0ƒ~40ƒ (32‰~104‰)
Storage Temperature: -40ƒ~70ƒ (-40‰~158‰)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
