INTERFACE

Fast Ethernet (RJ-45) Port *1（Support Passive PoE）

BUTTON

Reset

POWER SUPPLY

24V Passive PoE (+4,5pins; -7,8pins. PoE   Adapter Included)

POWER CONSUMPTION

2.8W

DIMENSIONS

7.5×6.8×1.2 in.
  (189.4×172.3×29.5mm)

ANTENNA TYPE

Internal 2* 4dBi Omni

MOUNTING

Ceiling /Wall Mounting (Kits included)

WIRELESS FEATURES

WIRELESS STANDARDS

IEEE 802.11n, IEEE 802.11g, IEEE 802.11b

FREQUENCY

2.4-2.4835GHz

SIGNAL RATE

11n: Up to 300Mbps(dynamic)
  11g: Up to 54Mbps(dynamic)
  11b: Up to 11Mbps(dynamic)

RECEPTION SENSITIVITY

300M: -71dBm@10% PER
  150M: -75dBm@10% PER
  54M: -78dBm@10% PER
  11M: -93dBm@8% PER
  6M: -92dBm@10% PER
  1M: -96dBm@8% PER

WIRELESS FUNCTIONS

Multiple SSIDs （Up to 8 SSIDs）
  Enable/Disable Wireless Radio
  Automatic Channel Assignment
  Transmit Power Control （Adjust Transmit Power on dBm）
  QoS(WMM)
  Rate Limit
  Reboot Schedule
  Wireless Schedule
  Wireless Statistics based on SSID/AP/Client

WIRELESS SECURITY

Captive Portal Authentication
  Access Control
  Wireless MAC Address Filtering
  Wireless Isolation Between Clients
  SSID to VLAN Mapping
  Rogue AP Detection
  802.1X Support
  64/128/152-bit WEP / WPA / WPA2-Enterprise,WPA-PSK / WPA2-PSK

TRANSMISSION POWER

CE:
  ≤19dBm(EIRP)
  FCC:
  ≤21dBm

MANAGEMENT

OMADA CLOUD ACCESS

Yes

OMADA APP

Yes

OMADA CLOUD CONTROLLER

Yes

OMADA CONTROLLER SOFTWARE

Yes

EMAIL ALERTS

Yes

LED ON/OFF CONTROL

Yes

MANAGEMENT MAC ACCESS CONTROL

Yes

SNMP

v1,v2c

SYSTEM LOGGING LOCAL/REMOTE SYSLOG

Local/Remote Syslog

TELNET

Yes

SSH

Yes

WEB-BASED MANAGEMENT

HTTP/HTTPS

MANAGEMENT VLAN

Yes

OTHERS

CERTIFICATION

CE, FCC, RoHS

PACKAGE CONTENTS

300Mbps Wireless N Ceiling Mount Access Point   EAP110
  Passive PoE Adapter,
  Power Cord,
  Mounting Kits,
  Installation Guide

SYSTEM REQUIREMENTS

Microsoft Windows 10/8/7/Vista/XP

ENVIRONMENT

Operating Temperature: 0℃~40℃   (32℉~104℉)
  Storage Temperature: -40℃~70℃   (-40℉~158℉)
  Operating Humidity: 10%~90% non-condensing
  Storage Humidity: 5%~90% non-condensing
