Standards and Protocols

• IEEE 802.3, 802.3u, 802.3ab, IEEE 802.3x, IEEE 802.1q

• TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP

Interface

• 1 Fixed Gigabit WAN Port

• 2 Fixed Gigabit LAN Ports

• 2 Changeable Gigabit WAN/LAN Ports

• 1 USB 2.0 Port (Connecting 4G/3G Modem as WAN Backup)

Network Media

• 10BASE-T: UTP category 3, 4, 5 cable (Max 100m)

EIA/TIA-568 100Ω STP (Max 100m)

• 100BASE-TX: UTP category 5, 5e cable (Max 100m)

EIA/TIA-568 100Ω STP (Max 100m)

• 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100m)

Button

Reset Button

Power Supply

External 12V/1A DC Adapter

Flash

128 MB NAND

DRAM

256 MB DDR

LED

PWR, SYS, WAN (Link/Act), LAN (Link/Act), USB

Dimensions   ( W x D x H )

6.2 × 4.0 × 1.0 in (158 × 101 × 25mm)

Max Power   Consumption

7.94 W

PERFORMANCE

Concurrent   Session

150,000

New   Sessions /Second

2,600

NAT   (Static IP)

• Upload: 945.77 Mbps

• Download: 945.56 Mbps

• Bi-Directional: 1808.29 Mbps

NAT(DHCP)

• Upload: 945.93 Mbps

• Download: 945.43 Mbps

• Bi-Directional: 1808.11 Mbps

NAT(PPPoE)

• Upload: 940.44Mbps

• Download: 940.52 Mbps

• Bi-Directional: 1804.27 Mbps

NAT (L2TP)

• Upload: 845.64 Mbps

• Download: 802.65 Mbps

• Bi-Directional: 931.96 Mbps

NAT (PPTP)

• Upload: 771.66 Mbps

• Download: 874.81 Mbps

• Bi-Directional: 999.54 Mbps

64 Byte Packet Forwarding Rate

• Upload/Download: 1,402,238 pps

• Bi-Directional: 1,681,548 pps

IPsec VPN Throughput

• ESP-MD5-AES256: 171.26 Mbps

• ESP-SHA1-AES256: 224.86 Mbps

• ESP-SHA2-AES256: 248.04 Mbps

OpenVPN

• 21.70 Mbps

L2TP VPN Throughput

• Unencrypted: 864.65 Mbps

• Encrypted: 47.11 Mbps

PPTP VPN Throughput

• Unencrypted: 703.20 Mbps

• Encrypted: 76.65 Mbps

BASIC FUNCTIONS

WAN Connection Type

• Static/Dynamic IP

• PPPoE

• PPTP

• L2TP

• Mobile Broadband: 4G/3G modem for backup via USB port

MAC Clone

Modify WAN/LAN MAC Address

DHCP

• DHCP Server/Client

• DHCP Address Reservation

• Multi-net DHCP*

• Multi-IP Interfaces*

IPv6

StaticIP / SLAAC / DHCPv6 / PPPoE / 6to4Tunnel / PassThrough

VLAN

802.1Q VLAN

IPTV

IGMP v2/v3 Proxy, Custom Mode, Bridge Mode

ADVANCED FUNCTIONS

ACL

IP/Port/Protocol/Domain Name Filtering

Advanced Routing

• Static Routing

• Policy Routing

Bandwidth Control

IP-based Bandwidth Control

Load Balance

• Intelligent Load Balance

• Application Optimized Routing

• Link Backup (Timing§, Failover)

• Online Detection

NAT

• One-to-One NAT§

• Multi-Net NAT

• Virtual Server

• Port Triggering§

• NAT-DMZ

• FTP/H.323/SIP/IPSec/PPTP ALG, UPnP

Security

• SPI Firewall

• VPN Passthrough

• FTP/H.323/PPTP/SIP/IPsec ALG

• DoS Defence, Ping of Death

• Local Management

Session Limit

IP-based Session Limit

VPN

IPsec VPN

• 20 IPsec VPN Tunnels

• LAN-to-LAN, Client-to-LAN

• Main, Aggressive Negotiation Mode

• DES, 3DES, AES128, AES192, AES256 Encryption Algorithm

• IKEv1/v2

• MD5, SHA1 Authentication Algorithm

• NAT Traversal (NAT-T)

• Dead Peer Detection (DPD)

• Perfect Forward Secrecy (PFS)

PPTP VPN

• PPTP VPN Server

• 10 PPTP VPN Clients**

• 16 Tunnels

• PPTP with MPPE Encryption

L2TP VPN

• L2TP VPN Server

• 10 L2TP VPN Clients**

• 16 Tunnels

• L2TP over IPSec

OpenVPN

• OpenVPN Server*

• 10 OpenVPN Clients*△

• 16 OpenVPN Tunnels*

SECURITY

Filtering

• WEB Group Filtering§

• URL Filtering

• Web Security§

ARP Inspection

• Sending GARP Packets§

• ARP Scanning§

• IP-MAC Binding§

Attack Defense

• TCP/UDP/ICMP Flood Defense

• Block TCP Scan (Stealth FIN/Xmas/Null)

• Block Ping from WAN

Access Control

Source/Destination IP Based Access Control

AUTHENTICATION

Web Authentication

• No Authentication

• Simple Password*

• Hotspot（Local User / Voucher* / SMS* /   Radius*）

• External Radius Sever

• External Portal Sever*

• Facebook*

MANAGEMENT

Omada App

Yes. Requiring the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller.

Centralized Management

• Omada Hardware Controller (OC300)

• Omada Hardware Controller (OC200)

• Omada Software Controller

• Omada Cloud-Based Controller

Cloud Access

Yes. Requiring the use of OC300, OC200, Omada Cloud-Based Controller,   or Omada Software Controller.

Service

Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe)

Maintenance

• Web Management Interface

• Remote Management

• Export & Import Configuration

• SNMP v1/v2c/v3

• Diagnostics (Ping & Traceroute)§

• NTP Synchronize§

• Syslog Support

Zero-Touch Provisioning

Yes. Requiring the use of Omada Cloud-Based Controller.

Management Features

• Automatic Device Discovery

• Intelligent Network Monitoring

• Abnormal Event Warnings

• Unified Configuration

• Reboot Schedule

• Captive Portal Configuration

OTHERS

Certification

CE, FCC, RoHS

Package Contents

• Gigabti VPN Router ER605 V2

• Power Adapter

• RJ45 Ethernet Cable

• Quick Installation Guide

System Requirements

Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10/11, MAC OS, NetWare, UNIX or Linux

Environment

• Operating Temperature: 0–40 ℃ (32–104 ℉);

• Storage Temperature: -40–70 ℃ (-40–158 ℉)

• Operating Humidity: 10–90% RH non-condensing

• Storage Humidity: 5–90% RH non-condensing
