Image Sensor

1/1.8” Progressive Scan CMOS

Day/Night Switch

Unified/ Scheduled/ Auto

Shutter Speed

1/3 to 1/10000 s

Slow Shutter

Yes

Minimum Illumination

0.0005 Lux; 0 Lux with white light

Day/Night Mechanism

NA

LENS

Type

Fixed Focal Lens

Focal Length

4 mm

Aperture

F1.0

FOV

4mm: Horizontal FOV: 95.2°, Vertical FOV: 50.6°, Diagonal FOV: 114.7°

Lens Mount

M16*P 0.5

DORI Distance

4 mm:

Detect: 70 m (231 ft)

Observe: 29 m (96 ft)

Recognize: 14 m (46 ft)

Identify: 7 m (23 ft)

ANGLE ADJUSTMENT (MANUAL)

Range

Pan: -90° to 90°

Tilt: -90° to 90°

ILLUMINATOR

IR LED

N/A

White LED

Quantity: 4

Range: 30m

Illuminator On/Off Control

Auto/Scheduled/Always on/Always off

VIDEO

Max. Resolution

2688 x 1520

Main Stream

Frame Rate：

50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps

60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps

Resolution:

2688x1520, 2560x1440, 2304x1296, 2048x1280, 1920x1080, 1280x720

Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.

Sub-Stream

Frame Rate：

50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps

60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps

Resolution:

705x576, 640x480, 352x288, 320x240

Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.

Bit Rate Control

CBR, VBR

Video Compression

Main Stream: H.265+/H.265/H.264+/H.264

Sub-Stream: H.265/H.264

H.264 Type

Main Profile/High Profile

H.264+

Main Stream Supported

H.265 Type

Main Profile

H.265+

Main Stream Supported

Video Bit Rate

Main Stream: 256 Kbps to 6 Mbps

Sub-Stream: 64 Kbps to 512 Kbps


Image Settings

Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR,   White Balance, HLC Adjustable by Client Software, Rotation (90°/270°)

Image Enhancement

BLC/3D DNR/HLC

Wide Dynamic Range

120 dB

SNR

≥ 52 dB

Image Parameters Switch

Yes

Privacy Mask

Up to 4 Masks

ROI

1 Region

OSD Setting

Yes

AUDIO

Audio Communication

Two-Way Audio

Audio Input

Yes

Audio Output

Yes

Audio Compression

Yes

Audio Sampling Rate

8KHz

Environment Noise Filtering

Yes

Audio Bit Rate

64 Kbps(G.711 alaw)

NETWORK

Protocol

TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP,   SSL/TLS

ONVIF

Yes

API

Open Network Video Interface (Profile S)

Simultaneous Live View

3 Main Streams & 3 Sub-Streams

Client

VIGI App, VIGI Security Manager, Web UI

Web Browser

Google Chrome® 57 and above

Firefox® 52 and above

Safari® 11 and above

Microsoft® Edge 91 and above

Cloud

Yes

Security

Password Protection, HTTPS Encryption, IP Address Filter, Digest   Authentication

ALARM AND EVENT MANAGEMENT

Smart Event

Human & Vehicle Classification, Area Intrusion Detection,   Line-Crossing Detection, People Detection, Vehicle Detection, Region Entering   Detection, Region Exiting Detection, Object Abandoned Detection, Object   Removal Detection, Loitering Detection, Scene Change Detection

Basic Event

Motion Detection, Video Tampering Detection, Exception (Illegal   Login), Scene Change Detection

Alarm Linkage

Linkage Method

N/A

Output Notification

Message Push

DEEP LEARNING FUNCTION

People & Vehicle Analytics

Search and filter to people or vehicle of interest based on many   different attributes, making post-event search faster and easier.

Face Capture

Support

Face Comparison

Support

INTERFACES

Network Interface

1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE

Alarm

N/A

Reset Button

Yes

Power

DC Power Port

On-board Storage

Built-In Memory Card Slot, Support MicroSD Card, Up to 256 GB

Built-in Microphone

Yes; Records Anything Going on within a 15-ft Radius of the Camera

Built-in Speaker

Yes

Audio

N/A

GENERAL

Operating Temperature

-30–60 °C

Storage Temperature

-40–60 °C

Operating Humidity

95% or Less (Non-Condensing)

Storage Humidity

95% or Less (Non-Condensing)

Package Contents

VIGI Network Camera

Quick Start Guide

Waterproof Cable Attachments

Mounting Accessories

Material

Front Cover: Metal

Back Cover: Plastic

Power Supply

12V DC ± 5%, Max. 10.1 W, 5.5mm Coaxial Power Plug

PoE: 802.3af/at, class 0, Max. 11.5 W

Protection

IP67

Product Dimensions (L x W x H)

102× 236× 99 mm

Certifications

CE, NTRA, VCCI, KC, BSMI, FCC, IC

Notes

^§Face Recognition and People & Vehicle Analytics can't be turned on   simultaneously. And Face Recognition requires VIGI NVR4032H for   operation.

SD card is not included in the package.

When Face Recognition s is enabled, only DWDR is supported.

^*VIGI ColourPro Night Vision image was captured by VIGI C340S.

^△This value is compared with the traditional F2.0 aperture, 1/3" target   surface sensor.

^**Calculations based on laboratory testing using a 3MP VIGI camera, and an actual performance may vary according to the amount of activity recorded, resolution and other variables.
